Xerox WorkCentre 5222 User Manual

February, 2008
6-62
WorkCentre 5225, 5230
Launch Version
General Procedures
770-061 Lpd Print Mode Type 1: Auto 1~29 1: Auto, 14: Dump, 15: ART, 16: PLW, 3: HPGL2, 8: ESCP, 5: PostScript, 10: TIFF, 2: PCL,
17: KS5843, 18: KSSM, 29: KS5895
770-062 Lpd JCL(FX)/PJL(AP) Enable 1 0~1 0: Off, 1: On
770-063 TBCP Valid Flag 0: None 0~1 0: None, 1: TBCP
770-064 Lpd Spool Mode 0: Non Spool 0~1 0: Non Spool, 1: Spool
770-065 Lpd Timeout 16sec 2~3600 2~3600sec (Setting range: 2~65,535)
770-068 Lpd Port Number 515 1~65535 1 to 65535
770-069 IT Option Address Null Can be entered in FQDN/IPv4/IPv6 literal format. The character string shall be null-termi-
nated. Restrictions: Only 1-byte alphanumerical characters, dots (.) used in the address as
separators, and colons (:) can be used.
770-070 Lpd Address Limitation 0: Do not limit 0~1 0: Do not limit, 1: Limit
770-077 SMTP Port Number 25 1~65535 25, 8000~9999
770-080 SMB Port Enable 1: Enable 0~1 0: Disable, 1: Enable
770-081 SMB Print Mode Type 1: Auto 1~29 1: Auto, 14: Dump, 15: ART, 16: PLW, 3: HPGL2, 8: ESCP, 5: PostScript, 10: TIFF, 2: PCL,
17: KS5843, 18: KSSM, 29: KS5895
770-082 SMB JCL(FX)/PJL(AP) Enable 1 0~1 0: Off, 1: On
770-083 SMB TBCP Valid Flag 0: None 0~1 0: None, 1: TBCP
770-084 SMB Spool Mode 0: Non Spool 0~1 0: Non Spool, 1: Spool
770-085 SMB Transport Protocol 6: Both 2~6 2: TCP/IP, 4: NetBeui, 6: Both
770-087 Timeout of BMLinkS Discovery 5 1~255 1 to 255 seconds
770-088 Max TTL of BMLinkS Discovery 1 1~10 1 to 10
770-089 Filtering Policy of BMLinkS Discovery 1 0~1 0: Not provided, 1: Provided
770-090 IPP Port Enable 0: Disable 0~1 0: Disable, 1: Enable
770-091 IPP Print Mode Type 1: Auto 1~29 1: Auto, 14: Dump, 15: ART, 16: PLW, 3: HPGL2, 8: ESCP, 5: PostScript, 10: TIFF, 2: PCL,
17: KS5843, 18: KSSM, 29: KS5895
770-092 IPP JCL(FX)/PJL(AP) Enable 1 0~1 0: Off, 1: On
770-093 IPP TBCP Valid Flag 0: None 0~1 0: None, 1: TBCP
770-094 Acl Authorization 0: Off (none) 0~1 1: On (local), 0: Off (none)
770-095 Use DNS Name 1: On 0~1 1: On, 0: Off
770-097 Port number 80 0~65535 0, 1 to 65535
770-098 IPP Spool Mode 0: Non Spool 0~1 0: Non Spool, 1: Spool
770-099 Timeout of IPP Port 60 0~65535 0~65535 sec.
770-100 DHCP Mode 2: DHCP 1~16 16: Manual, 4: BOOTP, 2: DHCP, 1: RARP
770-104 IP Mode 10 4~10 4: Activate IPv4 Protocol only, 6: Activate IPv6 Protocol only, 10: Activate both IPv4 and
IPv6 Protocols
770-110 DNS Auto Config. 0x02 0~0x10 0x10: Manual setting, 0x02: DHCP
770-112 DNS Domain Name NULL DNS Domain Name (Usually 255 characters or less including the last “.” (dot) that is not dis-
played.)
770-113 WSD Print Starting Setup 1 0~1 0: Disable, 1: Enable
770-114 WSD Print Port No. 80 1~65535 1 to 65535
Table 5 I/O Port Protocol
Chain-
Link Content Default Range Meaning

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
