Xerox WorkCentre 5222 User Manual

February, 2008
6-64
WorkCentre 5225, 5230
Launch Version
General Procedures
Chain 770-xxx 840-xxx Scan Service
770-159 IPv6 Gateway Address for Auto Configura-
tion
Null Indicates IPv6 address in (null-terminated) literal format (prefix is 64 bits)
770-160 MFIO Port Enable 0: Disable 0~1 0: Disable, 1: Enable
770-163 SNMP Protocol version 1 1~255 1: V1/V2C, 2: V3 (The bit corresponding to the valid bit is turned on)
770-166 HTTP Max Session 5 1~15 1~15
770-179 SLP Version 1 1~2 1: PFRSC_SYS_SLP_V1, 2: PFRSC_SYS_SLP_V2
770-190 Mail Service Start/Stop 1: Start 0~1 1: Start, 0: Stop
770-191 Address of Mail Sender NULL ASCII Max number of characters 128 (Character type: alphabet, [@] [.] [+] [-] [=] [_] (under-
score) [/] [<] [>]) in the format username@domain.name
770-222 port9100 Starting setup 1 0~1 0: Disable 1: Enable
770-250 USB Adobe Protocol 0 0~3 0: Standard 1: Binary 2: TBCP, 3: RAW Mode
770-251 USB JCL(FX)/PJL(AP) Enable 1 0~1 0: Off 1: On
770-252 USB Print Mode Type 1 1~29 1: Auto, 14: Dump, 15: ART, 16: PLW, 3: HPGL2, 8: ESCP, 5: PostScript, 10: TIFF, 2: PCL,
17: KS5843, 18: KSSM, 29: KS5895 Refer to the FF Host I/F of each product for the setting
range.
770-254 USB Port Enable 1 0~1 0: Disable 1: Enable
770-255 USB Auto Feed Time 6 (30sec) 1~255 1~255 (5~1275 sec.) (unit: 5 sec.)
770-280 Mail Print Starting Setup 1: Enable 0~1 0: Disable, 1: Enable
770-281 Mail Print File Type 1 1~29 1: Auto, 14: Dump, 15: ART, 16: PLW, 3: HPGL2, 8: ESCP, 5: PostScript, 10: TIFF, 2: PCL,
17: KS5843, 18: KSSM, 29: KS5895
770-282 Mail Print JCL Switch 1 0~1 0: Off, 1: On
770-283 Mail Print Filter 0 0~1 0: None, 1: TBCP
770-284 Mail Print Spool Type 0: Non Spool 0~1 0: Non Spool (Ring Buffer), 1: Spool (RAM Disk)
770-285 Mail Print with Header Print 1: Print basic headers and
contents
0~4 0: Print all headers and contents, 1: Print basic headers and contents, 2: Do not print head-
ers or contents, 3: Auto print according to content, 4: Print entire header and body (S/MIME
data included)
770-286 POP Server User Name NULL -
770-287 POP Server Password NULL -
770-290 UPnP Enable 1: Enable 0~1 0: Disable 1: Enable
770-291 UPnP Port Number 80 1~65535 1 to 65535
770-295 BMLinkS Print Service Enable 1: Enable 0~1 0: Disable 1: Enable
770-296 BMLinkS Discovery Service Port No. 80 1~65535 1 to 65535
770-297 BMLinkS Print Service Port No. 80 1~65535 1 to 65535
770-320 Sesami Port Enable 1: Enable 0~1 0: Disable, 1: Enable
Table 5 I/O Port Protocol
Chain-
Link Content Default Range Meaning
Table 6 Scan Service
Chain-
Link
Content Default Range Meaning
770-301 LDAP Server Name Primary NULL 64bytes or below. Refer to RFC1034 for the available characters.

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
