Xerox WorkCentre 5222 User Manual

February, 2008
6-66
WorkCentre 5225, 5230
Launch Version
General Procedures
840-031 Switch System of ServerFax and Enbed-
dedFax
1 1~2 1: Priority on Server Fax, 2: Priority on Analog Fax
840-032 ServerFax Confirmation Sheet Control 2 1~3 1: Always output report, 2: Output report only when error occurs, 3: Do not output report
840-034 ServerFax Transfer Protocol 1 1~5 1: FTP, 2: NCP, 3: SMB, 4: SMTP, 5: HTTP
840-041 SMB Browsing Timeout Setting 5 1~300 1 to 300 seconds
840-046 Use cn for LDAP Search Filter 1 1~2 1: On, 2: Off
840-047 Use sn for LDAP Search Filter 2 1~2 1: On, 2: Off
840-048 Use givenname for LDAP Search Filter 2 1~2 1: On, 2: Off
840-049 Use custom attribute for LDAP Search Fil-
ter
2 1~2 1: On, 2: Off
840-080 ABL LDAP Valid 1 0~1 1: Allow, 0: Prohibit
840-081 ABL LDAP CN cn Character string within 32bytes.
840-082 ABL LDAP SN sn Character string within 32bytes.
840-083 ABL LDAP Given Name given name Character string within 32bytes.
840-084 ABL LDAP Mail mail Character string within 32bytes.
840-085 ABL LDAP Alt Name1 Telephone number (FX
default)
Character string within 16bytes (for Japan). Default character string differs per shipment
destination.
840-086 ABL LDAP Alt Name1 Type Telephone number Character string within 32bytes.
840-087 ABL LDAP Alt Name2 Office (FX default) Character string within 16bytes (for Japan). Default character string differs per shipment
destination.
840-088 ABL LDAP Alt Name2 Type o Character string within 32bytes.
840-089 ABL LDAP Alt Name3 Department (FX default) Character string within 16bytes (for Japan). Default character string differs per shipment
destination.
840-090 ABL LDAP Alt Name3 Type ou Character string within 32bytes.
840-091 ABL LDAP Max Hit Count 50 5~100
840-092 ABL LDAP DN NULL Within 256bytes. Do not set if LDAP authentication is not required.
840-093 ABL LDAP Password NULL Within 32bytes. Do not set if password is not required in LDAP authentication.
840-094 ABL LDAP Root NULL Within 255bytes.
840-095 ABL LDAP Scope 3 1~3 1: Root entry only, 2: One level below root entry only, 3: All levels below root entry
840-096 ABL LDAP Object Class * Within 32bytes.
840-097 ABL LDAP Timeout 30 For 0 or 5~120 detected by the device, set the timeout value to a numerical value other than
0. If 0 is specified, the device will not detect timeout. The timeout setting will follow the set
-
ting in the Directory Server Service.
840-098 ABL LDAP Directory Application NULL 0~3 0: None (other application server that is not defined), 1: Microsoft (ActiveDirectory or
Microsoft ExchangeServer5.5), 2: Novel* NetWare5*, 3: IBM Domino 6*.
* Mapping of properties for retrieval and LDAP properties are done based on this setting.
840-104 Custom Attribute for LDAP Search Filter NULL Maximum of 32 bytes including null-terminated character string. Upper case and lower case
letters are distinguished. For this system data’s character string to be valid, “Use of Custom
LDAP Attribute Type” needs to be set to “On.”
840-115 Scan Template Management Enable 0 0~1 0: Do not enable, 1: Enable
840-116 Scan to E-Mail Net Config Sign 3 1~3 1: Always place signature, 2: Never place signature, 3: User selection
840-117 IFAX Net Config Sign 3 1~3 1: Always place signature, 2: Never place signature, 3: User selection
Table 6 Scan Service
Chain-
Link Content Default Range Meaning

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
