February, 2008
6-117
WorkCentre 5225, 5230
Initialize HFSI Counters
General Procedures
Launch Version
IIT PF-HFSI/Recycle List
Table 2 IIT HFSI
Chain-Link Name
Initial
Value
Setting
Range
Count Condition Remarks
956-802 IIT Scan 0 0~6,881,175 Scan Count (including pre-Scan)
Counts up with each scan.
HFSI to Scan count after clearing HFSI Counter
Recycle to Total Scan count without clearing
1 time increments
Max count value=above 6,000,000 times
Only count Platen Scans, not CVT Scans.
956-803 Lamp ON Time 0 0~7,864,200 Lamp ON Time
Starts timing when the lamp turns on.
Stops timing when the lamp turns off.
Writes to the NVM during CRG Initialize.
HFSI to Lamp ON time after clearing HFSI
Counter
Recycle to Total Lamp ON time without clearing
Lamp Life 2000 hours
1 time increments
Max count value=7,200,000sec and above
Times the total duration when the lamp is on (including AGOC, Lamp Check).
956-804 Lamp ON Count 0 0~6,881,175 Lamp ON count after clearing HFSI Counter
Counts up when the lamp turns on.
Writes to the NVM during CRG Initialize.
Lamp Life 6,000,000 times
1 time increments
Max count value=above 6,000,000 times
Counts the number of times the lamp turns on (including AGOC, Lamp
Check).
956-808 Platen Open/Close Count
(Platen models)
0 0~1,966,050 Counts up when the Angle Sensor is forced fully
open.
1 time increments
Max count value=above 1,000,000 times
955-806 Document Feed (CVT,
DADF models)
0 0~5,000,000 Counts up when the Feed Sensor turns on.
HFSI to Document Feed count after clearing HFSI
Counter
Recycle to Total Document Feed count without
clearing
Number of sheets fed from the CVT Tray
The NVM is controlled by the CVT.
955-807 Document Feed Simp
(CVT, DADF models)
0 0~5,000,000 Counts the number of document sheets fed in
Simplex mode.
The NVM is controlled by the CVT.
* Life is common to 955-808.
955-808 Document Feed Dup
(CVT, DADF models)
0 0~5,000,000 Counts the number of document pages fed in
Duplex mode.
Counts up when Invert Sensor turns off during
Duplex transport.
The NVM is controlled by the CVT.
* Life is common to 955-807.
955-810 Platen Open/Close Count
(CVT, DADF models)
0 0~1,000,000 Counts up when the Platen Interlock is open. Belt/CVT judgement is processed in the IISS.
The NVM is controlled by the CVT.
955-829 Invert Solenoid ON Count 0 0~5,000,000 Counts up when the Invert Solenoid turns on.
HFSI to Invert Solenoid ON count after clearing
the counter
Recycle to Total Invert Solenoid ON count without
clearing
CVT(PF2)
The NVM is controlled by the CVT.
955-830 DADF Stamp Solenoid
ON Count (Solenoid Life)
0 0~300,000 Counts up when the Stamp Solenoid turns on.
HFSI to Stamp Solenoid ON count after clearing
the counter
Recycle to Total Stamp Solenoid ON count without
clearing
CVT(PF2)
The NVM is controlled by the CVT.
To Next Page
