February, 2008
6-132
WorkCentre 5225, 5230
Component Control
Launch Version
General Procedures
005-221 CVT-DADF Tray Size SNR Number1 L paper detected by Tray Size SNR Number1 Not Available
005-222 CVT-DADF Tray Size SNR Number2 L paper detected by Tray Size SNR Number2 Not Available
005-224 Scan Start H Scan Start Signal ON Not Available
005-225 Nudger Position Snr H The Nudger Roll is at UP position. Not Available
062-201 Sheet Abort L Document Regist Not Available
062-212 IIT Regi Sensor L De-actuation of Regi Sensor Not Available
062-240 ADF Exist H DADF is not installed Not Available
062-251 APS Sensor1 APS SNR1:L APS ON: H Document detected Not Available
062-253 APS Sensor3 APS SNR3:L APS ON: H Document detected Not Available
062-272 Scan Start L Scan available Not Available
062-300 Platen I/L Switch L Platen closed Not Available
062-301 Angle Sensor L Platen opened Not Available
Table 4 Output Component Control Codes IIT
Chain-Link Name Connector Level Meaning Timer Off
Multiple Output
Prohibited Items
Remarks
005-001 CVT-DADF Feed Motor(Speed1) - ON for 50sec -> Auto OFF O 005-002~005-014 Not Available
005-002 CVT-DADF Feed Motor(Speed2) - ON for 50sec -> Auto OFF O 005-001
005-003~005-014
Not Available
005-003 CVT-DADF Feed Motor(Speed3) - ON for 50sec -> Auto OFF O 005-001~005-002
005-004~005-014
Not Available
005-004 CVT-DADF Feed Motor(Speed4) - ON for 50sec -> Auto OFF O 005-001~005-003
005-005~005-014
Not Available
005-005 CVT-DADF Feed Motor(Speed5) - ON for 50sec -> Auto OFF O 005-001~005-004
005-006~005-014
Not Available
005-006 CVT-DADF Feed Motor(Speed6) - ON for 50sec -> Auto OFF O 005-001~005-005
005-007~005-014
Not Available
005-007 CVT-DADF Feed Motor(Speed7) - ON for 50sec -> Auto OFF O 005-001~005-006
005-008~005-014
Not Available
005-008 CVT-DADF Feed Motor(Speed8) - ON for 50sec -> Auto OFF O 005-001~005-007
005-009~005-014
Not Available
005-009 CVT-DADF Feed Motor(Speed9) - ON for 50sec -> Auto OFF O 005-001~005-008
005-010~005-014
Not Available
005-010 CVT-DADF Feed Motor(Speed10) - ON for 50sec -> Auto OFF O 005-001~005-009
005-013~005-014
Not Available
005-013 CVT-DADF Feed Motor(Speed11) - ON for 50sec -> Auto OFF O 005-001~005-010
005-014
Not Available
005-014 CVT-DADF Feed Motor(Reverse) - ON for 50sec -> Auto OFF O 005-001~005-013 Not Available
005-026 CVT-DADF Reg.Motor(Speed1) - ON for 50sec -> Auto OFF O 005-027~005-036 Not Available
005-027 CVT-DADF Reg.Motor(Speed2) - ON for 50sec -> Auto OFF O 005-026
005-028~005-036
Not Available
Table 3 Input Component Control Codes IIT
Chain-Link Name Connector Level Meaning Remarks

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
