Xerox WorkCentre 5222 User Manual

February, 2008
2-371
WorkCentre 5225, 5230
024-976, 024-977
Status Indicator Raps
Launch Version
024-976 Finisher Staple Status Failed RAP
BSD-ON:12.21
• After the Stapler Motor turned On (Forward rotation), the system did not detect that the
Staple Head Home Sensor switched from Off to On within the specified time.
• After the Stapler Motor turned On (Reverse rotation), the Staple Head Home Sensor did
not turn On within the specified time.
Procedure
Alternately execute Component Control[012-046 Staple Motor FORWARD ON] and Compo-
nent Control[012-047 Staple Motor REVERSE ON]. The Stapler Motor can be heard.
YN
Check the connections of J8887 and P/J8981. J8887 and P/J8981 are connected
correctly.
YN
Connect J8887 and P/J8981.
Check the wire between J8887 and J8981 for an open circuit or a short circuit (BSD
12.24).
The wire between J8887 and J8981 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Replace the Staple Assembly (PL 23.8). If the problem persists, replace the Finisher PWB
(PL 23.16).
Execute Component Control[012-244 Staple Head Home Sensor]. Alternately execute Com-
ponent Control[012-046 Staple Motor FORWARD ON] and Component Control[012-047 Staple
Motor REVERSE ON].
The display changes.
YN
Check the connections of P/J8896 and P/J8981. P/J8896 and P/J8981 are con-
nected correctly.
YN
Connect P/J8896 and P/J8981.
Check the wire between J8886 and J8981 for an open circuit or a short circuit (BSD
12.21).
The wire between J8886 and J8981 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Finisher PWB P8852-1 (+) and GND (-) (BSD 12.21).
The voltage is approx. +5VDC.
YN
Replace the Finisher PWB (PL 23.16).
Replace the Staple Assembly (PL 23.8). If the problem persists, replace the Finisher PWB
(PL 23.16).
Replace the Finisher PWB (PL 23.16). If the problem persists, replace the MCU PWB (PL 9.1).
024-977 Stapler Feed Ready Failure RAP
BSD-ON:12.21
When starting Staple, Staple Ready Sensor Off was detected.
Empty stapling was within 13 times.
Initial Actions
Reload the Staple Cartridge.
Procedure
Execute Component Control[012-243 Staple Ready Sensor]. Install and remove the Staple
Cartridge.
The display changes.
YN
Check the Staple Cartridge for failure or foreign substances. There are no foreign sub-
stances and nothing has failed.
YN
Repair the failure and remove the foreign substances.
Check the connections of J8886 and P/J8981. J8886 and P/J8981 are connected
correctly.
YN
Connect J8886 and P/J8981.
Check the wire between J8886 and J8981 for an open circuit or a short circuit (BSD
12.21).
The wire between J8886 and J8981 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Finisher PWB P8981-4 (+) and GND (-) (BSD 12.21).
The voltage is approx. +5VDC.
YN
Replace the Finisher PWB (PL 23.16).
Measure the voltage between the Finisher PWB P8981-6 (+) and GND (-) (BSD 12.21).
Install and remove the Staple Cartridge.
The voltage changes.
YN
Replace the Finisher PWB (PL 23.16).
Replace the Staple Assembly (PL 23.8). If the problem persists, replace the Finisher PWB
(PL 23.16).
Replace the Finisher PWB (PL 23.16). If the problem persists, replace the MCU PWB (PL 9.1).

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
