Xerox WorkCentre PE16 - In the Fuser Area or Around the Toner Cartridge

T ROUBLESHOOTING
8.7
8
5 Close the rear cover.
6 Open and close the front cover to resume printing.
In the Fuser Area or Around the Toner
Cartridge
NOTE: The fuser area is hot. Take care when removing paper
from the machine.
1 Open the front cover and pull the toner cartridge out,
lightly pushing it down.
2 Remove the jammed paper by gently pulling it straight out.
