FusionServer 2288H V6 Server
Technical White Paper
5 Hardware Description
2022-06-25
130
(SLIMLINE7/J31)
CONN/J109)
7
Built-in storage expansion
port (SD CARD/J87)
8
2 x USB 3.0 ports (USB3.0
CONN/J88)
9
Rear VGA port (VGA
CONN/J60)
10
Serial port (COM/J6020)
11
BMC management network
port (BMC_GE /J6019)
12
BMC management board
13
LCD connector (LCD
CONN/J6025)
14
OCP 3.0 network adapter 1
connector (OCP1
CONN/J108)
15
Rear-drive backplane power
connector 2 (REAR BP
PWR2/J21)
16
NC-SI connector (NCSI
CONN/J114)
17
LP slimline 6 connector for
OCP 3.0 network adapter 1
(SLIMLINE6/J13)
18
PCIe riser 1 slot (PCIE
RISER1/J50)
19
TPM/TCM connector (J10)
20
mini-SAS HD connector C
(MINIHD PORTC/J4)
21
Drive backplane power
connector 3 (HDD BP
PWR3/J89)
22
Built-in USB 3.0 connector
(INNER USB3.0/J110)
23
Right mounting ear connector
(RCIA BOARD/J113)
24
mini-SAS HD connector B
(MINIHD PORTB/J5)
25
Rear-drive backplane power
connector 1 (REAR BP
PWR1/J64)
26
mini-SAS HD connector A
(MINIHD PORTA/J6)
27
SATA connector 1
(SATA1/J1)
28
SATA connector 2
(SATA2/J2)
29
Cell battery holder (U9)
30
VROC key connector (Soft
RAID KEY/J3)
a
31
LP slimline 1 connector
(SLIMLNE1/J11)
32
LP slimline 2 connector
(SLIMLNE2/J84)
33
Fan module 4 connector
(J100)
34
Fan module 4 connector (2U
FAN4/J98)
35
Fan module 3 connector (J97)
36
Fan module 3 connector (2U
FAN3/J95)
37
Intrusion sensor connector
(INTRUDER CONN/S1)
38
Fan module 2 connector (J93)
39
Low-speed signal connector
for the front-drive backplane
(FRONT HDD BP/J75)
40
Fan module 2 connector (2U
FAN2/J91)
41
Fan module 1 connector
42
Fan module 1 connector (2U
