FusionServer 2288H V6 Server
Technical White Paper
5 Hardware Description
2022-06-25
73
Drive No.
Drive Number Identified
by the iBMC
Drive Number Identified
by the RAID Controller
Note: If the slot is configured with a SAS/SATA drive, the RAID controller card can
manage the drive and allocate a number to the drive.
5.1.5.1.4 12 x 3.5" Drive EXP configuration
Drive configuration
Table 5-25 Drive configuration
Configuration
Front Drive
Rear Drive
Built-in Drive
Drive
Management
Mode
12 x 3.5" drive
EXP
configuration 1
⚫
Front drive:
12 x 3.5"
− Slots 0 to
11
support
only
SAS/SAT
A drives.
⚫
I/O module
1: 2 x 2.5"/2
x 3.5"
− Slots 40
and 41
support
only
SAS/SAT
A drives.
⚫
I/O module
2: 2 x 3.5"
− Slots 42
and 43
support
only
SAS/SAT
A drives.
⚫
I/O module
3: 4 x 2.5"
− Slots 44
to 47
support
SAS/SAT
A/NVMe
drives
a
.
⚫
Built-in
drive: 4 x
3.5"
− Slots 36
to 39
support
only
SAS/SAT
A drives.
⚫
SAS/SATA
drive: 1 x
screw-in
RAID
controller
card
⚫
NVMe
drive: CPU
12 x 3.5" drive
EXP
configuration 2
⚫
Front drive:
12 x 3.5"
− Slots 0 to
11
support
only
SAS/SAT
A drives.
⚫
I/O module
1: 2 x 2.5"
− Slots 40
and 41
support
only
SAS/SAT
A drives.
⚫
Built-in
drive: 4 x
3.5"
− Slots 36
to 39
support
only
SAS/SAT
⚫
SAS/SATA
drive: 1 x
PCIe RAID
controller
card
⚫
NVMe
drive: CPU
