5 Hardware Description
2022-06-25
47
No.
Description
Example
1
Component
Intel Optane
TM
Persistent Memory
2
SN
8089-A2-2008-00002461
3
Model
NMB1XXD512GPSU4
4
Capacity (GB)
⚫
128
⚫
256
⚫
512
5
SN QR code
8089-A2-2008-00002461
5.1.4.2.2 Memory Subsystem Architecture
The server provides 32 memory slots. Each processor integrates eight memory channels, and
each memory channel supports only one PMem module.
PMem modules must be used with DDR4 memory modules.
Table 5-7 Memory channels
CPU
Channel
Memory Slot
CPU 1
A (primary)
DIMM000(A)
A
DIMM001(I)
B (primary)
DIMM010(B)
B
DIMM011(J)
C (primary)
DIMM020(C)
C
DIMM021(K)
D (primary)
DIMM030(D)
D
DIMM031(L)
E (primary)
DIMM040(E)
E
DIMM041(M)
F (primary)
DIMM050(F)
F
DIMM051(N)
G (primary)
DIMM060(G)
G
DIMM061(O)
H (primary)
DIMM070(H)
H
DIMM071(P)
CPU2
A (primary)
DIMM100(A)
