xFusion Digital Technologies FusionServer 2288H V6

FusionServer 2288H V6 Server
Technical White Paper
5 Hardware Description
2022-06-25
141
Figure 5-112 Front view
1
Drive
2
Slide-out label plate (with an
SN label)
5.2.1.2 Indicators and Buttons
Indicator and Button Positions
⚫
8 x 2.5" drive configuration
Figure 5-113 Indicators and buttons on the front panel
1
Fault Diagnosis LED
2
Power Button/Indicator
3
Health status indicator
4
UID button/indicator
5
FlexIO card presence
indicator
-
-
⚫
12 x 3.5" drive configuration
Figure 5-114 Indicators and buttons on the front panel
