xFusion Digital Technologies FusionServer 2288H V6 User Manual

FusionServer 2288H V6 Server
Technical White Paper
5 Hardware Description
2022-06-25
150
CPU
Channel
Memory Slot
CPU 1
A
DIMM000(A)
B
DIMM010(B)
C
DIMM020(C)
D
DIMM030(D)
E
DIMM040(E)
F
DIMM050(F)
G
DIMM060(G)
H
DIMM070(H)
CPU 2
A
DIMM100(A)
B
DIMM110(B)
C
DIMM120(C)
D
DIMM130(D)
E
DIMM140(E)
F
DIMM150(F)
G
DIMM160(G)
H
DIMM170(H)
5.2.4.1.3 Memory Compatibility
Observe the following rules when configuring DDR4 memory modules:
⚫
A server must use DDR4 memory modules of the same part number (P/N code), and the
memory speed is the minimum value of the following items:
⚫
Memory speed supported by a CPU
⚫
Maximum operating speed of a memory module
⚫
The DDR4 DIMMs of different types (RDIMM and LRDIMM) and specifications
(capacity, bit width, rank, and height) cannot be used together.
⚫
Contact your local sales representative or see "Search Parts" in the Compatibility Checker
to determine the components to be used.
⚫
The memory can be used with the third-generation Intel
®
Xeon
®
Scalable Ice Lake
processors. The maximum memory capacity supported by all processor models is the
same.
⚫
The total memory capacity is the sum of the capacity of all DDR4 memory modules.

xFusion Digital Technologies FusionServer 2288H V6 Specifications

General

Brand	xFusion Digital Technologies
Model	FusionServer 2288H V6
Category	Server
Language	English
