xFusion Digital Technologies FusionServer 2288H V6

FusionServer 2288H V6 Server
Technical White Paper
5 Hardware Description
2022-06-25
87
Drive No.
Drive Number Identified
by the iBMC
Drive Number Identified
by the RAID Controller
3
3
3
4
4
-
5
5
-
6
6
-
7
7
-
8
8
-
9
9
-
10
10
-
11
11
-
16
16
-
17
17
-
18
18
-
19
19
-
20
20
-
21
21
-
22
22
-
23
23
-
44
44
4
45
45
5
46
46
6
47
47
7
5.1.5.1.6 24 x 2.5" Drive Pass-through configuration
Drive configuration
Table 5-33 Drive configuration
Configuration
Front Drive
Rear Drive
Built-in Drive
Drive
Management
Mode
24 x 2.5" drive
NVMe
configuration 1
⚫
Front drive:
24 x 2.5"
− Slots 0 to
-
-
⚫
SATA
drive: PCH
⚫
NVMe
