xFusion Digital Technologies FusionServer 2288H V6

FusionServer 2288H V6 Server
Technical White Paper
6 Product Specifications
2022-06-25
195
6 Product Specifications
6.1 2288H V6-32DIMM
6.2 2288H V6-16DIMM
6.1 2288H V6-32DIMM
6.1.1 Technical Specifications
Table 6-1 Technical specifications
Component
Specifications
Form factor
2U rack server
Chipset
Intel
®
C621A
Processor
Supports one or two processors.
⚫
Third-generation Intel
®
Xeon
®
Scalable Ice Lake
processors
⚫
Built-in memory controller and eight memory channels per
processor
⚫
Built-in PCIe controller, supporting PCIe 4.0 and 64 lanes
per processor
⚫
Three UPI buses between processors, providing up to 11.2
GT/s transmission per channel
⚫
Up to 40 cores
⚫
Max. 3.6 GHz
⚫
Min. 1.5 MB L3 cache per core
⚫
Max. 270 W TDP
NOTE
The preceding information is for reference only. For details, see
"Search Parts" in the Compatibility Checker.
DIMM
Supports 32 memory module slots.
⚫
Up to 32 DDR4 memory modules
