xFusion Digital Technologies FusionServer 2288H V6 User Manual

FusionServer 2288H V6 Server
Technical White Paper
A Appendix
2022-06-25
218
A Appendix
A.1 Chassis Label
The label information and location are for reference only. For details, see the actual product.
A.1.1 On the Front Top
Figure A-1 Chassis head label
1
Nameplate
2
Certificate
3
Quick access tag
4
SN
NOTE
For details, see A.2 Product SN.
5
Reserved space for custom label
6
Pressure-proof label
NOTE
This label indicates that do not place
any objects on top of a rack-mounted

xFusion Digital Technologies FusionServer 2288H V6 Specifications

General

Processor	Intel Xeon Scalable processors
Max Processors	2
Form Factor	2U
Memory	Up to 3TB
Memory Slots	32
Storage	Up to 12x 3.5" or 24x 2.5" drives
RAID Support	RAID 0, 1, 10, 5, 50, 6, or 60
Network	Dual 10GbE ports
Expansion Slots	Up to 7
PCIe Slots	7
Power Supply	Redundant 550W/800W/1200W
