FusionServer 2288H V6 Server
Technical White Paper
3 Physical Structure
2022-06-25
15
7
Air duct
NOTE
The air duct cannot be installed
on a server with built-in drives.
8
Intrusion sensor
9
Front-drive backplane
10
Left mounting ear plate
11
Fan module brackets
12
Fan module
13
Front drive
14
Right mounting ear plate
15
Processor heat sink
16
Processor
17
Cable organizer
18
Mainboard
19
BMC card
20
OCP 3.0 network adapter
21
Screw-in RAID controller
card
22
TPM/TCM
23
Memory
-
-
3.2 2288H V6-16DIMM
Figure 3-2 Physical structure of a server with 12 x 3.5" drives (example)
1
I/O module 1
2
PCIe Card
