xFusion Digital Technologies FusionServer 2288H V6 User Manual

FusionServer 2288H V6 Server
Technical White Paper
3 Physical Structure
2022-06-25
16
3
PSU
4
Chassis
5
I/O module 3
6
Supercapacitor holder
7
Air duct
NOTE
The air duct cannot be installed
on a server with built-in drives.
8
Intrusion sensor
9
Front-drive backplane
10
Left mounting ear plate
11
Fan module brackets
12
Fan module
13
Front drive
14
Mainboard
15
Processor
16
Processor heat sink
17
Built-in PCIe card
18
Install the guide trough for the
built-in standard card
19
Memory
20
TPM/TCM
21
Screw-in RAID controller
card
22
OCP 3.0 network adapter
