5.1.5 Storage
5.1.5.1 Drive Configurations
5.1.5.1.1 8 x 2.5" Drive Pass-through configuration
Drive configuration
Table 5-9 Drive configuration
Configuration
Front Drive
Rear Drive
Built-in Drive
Drive
Management
Mode
8 x 2.5" drive
pass-through
configuration 1
⚫
Front drive:
8 x 2.5"
− Slots 0 to
7 support
only
SATA
drives.
⚫
I/O module
3: 4 x 2.5"
− Slots 44
to 47
support
only
NVMe
drives
a
.
-
⚫
SATA
drive: PCH
⚫
NVMe
drive: CPU
8 x 2.5" drive
pass-through
configuration 2
⚫
Front drive:
8 x 2.5"
− Slots 0 to
7 support
only
SAS/SAT
A drives.
⚫
I/O module
3: 4 x 2.5"
− Slots 44
to 47
support
only
NVMe
drives
a
.
-
⚫
SAS/SATA
drive: 1 x
screw-in
RAID
controller
card
⚫
NVMe
drive: CPU
8 x 2.5" drive
pass-through
configuration 3
⚫
Front drive:
8 x 2.5"
− Slots 0 to
7 support
only
SAS/SAT
A drives.
⚫
I/O module
3: 4 x 2.5"
− Slots 44
to 47
support
only
NVMe
drives
a
.
-
⚫
SAS/SATA
drive: 1 x
PCIe RAID
controller
card
⚫
NVMe
drive: CPU
8 x 2.5" drive
pass-through +
11 x PCIe card
configuration 1
⚫
Front drive:
8 x 2.5"
− Slots 0 to
7 support
only
SATA
drives.
-
-
⚫
PCH
passthrough
8 x 2.5" drive
pass-through +
11 x PCIe card
configuration 2
⚫
Front drive:
8 x 2.5"
− Slots 0 to
7 support
-
-
⚫
1 x screw-in
RAID
controller
card
