FusionServer 2288H V6 Server
Technical White Paper
5 Hardware Description
2022-06-25
194
1
Indicator signal cable
connector (REAR BP/J5)
2
mini-SAS HD connector
(REAR PORT/J2)
3
Power connector (BP
PWR/J1)
-
-
1
LP slimline 4 connector
(SLIM_4/J1001)
2
Power connector
(POWR/J2502)
3
LP slimline 3 connector
(SLIM_3/J901)
4
Backplane signal cable
connector (HDD BP/J2302)
5
mini-SAS HD connector (Port
A/J801)
-
-
