xFusion Digital Technologies FusionServer 2288H V6

FusionServer 2288H V6 Server
Technical White Paper
5 Hardware Description
2022-06-25
159
Configuration
Front Drive
Rear Drive
Built-in Drive
Drive
Management
Mode
12 x 3.5" drive
pass-through
configuration 3
(4 x NVMe)
⚫
Front drive:
12 x 3.5"
− Slots 0 to
7 support
only
SAS/SAT
A drives.
− Slots 8 to
11
support
SAS/SAT
A/NVMe
drives.
⚫
I/O module
1: 2 x 3.5"
− Slots 40
and 41
support
only
SAS/SAT
A drives.
-
⚫
SAS/SATA
drive: 1 x
PCIe RAID
controller
card
The PCIe
RAID
controller
card must be
installed in
slot 1.
⚫
NVMe
drive: CPU
⚫
a: The server with CPU 2 supports NVMe drives, but the server with a single CPU does
not support NVMe drives.
⚫
Contact your local sales representative or see "Search Parts" in the Compatibility
Checker to determine the components to be used.
Slot numbers
⚫
Drive slot numbers of 12 x 3.5" drive pass-through configuration 1 in Table 5-57
Figure 5-126 Slot numbers
Table 5-58 Slot numbers
Drive No.
Drive Number Identified by the iBMC
0
0
1
1
2
2
