5 Hardware Description
2022-06-25
172
Configuration
Front Drive
Rear Drive
Built-in Drive
Drive
Management
Mode
SAS/SAT
A drives
in slots
40 to 41.
− The PCIe
RAID
controlle
r card
manages
SAS/SAT
A drives
in slots 0
to 24.
⚫
NVMe
drive: CPU
⚫
a: The server with CPU 2 supports NVMe drives, but the server with a single CPU does
not support NVMe drives.
⚫
Contact your local sales representative or see "Search Parts" in the Compatibility
Checker to determine the components to be used.
Slot numbers
⚫
Drive slot numbers of 25 x 2.5" drive EXP configuration 1 and 25 x 2.5" drive EXP
configuration 2 in Table 5-66
Figure 5-133 Slot numbers
Table 5-67 Slot numbers
Drive No.
Drive Number Identified
by the iBMC
Drive Number Identified
by the RAID Controller
0
0
0
