5 Hardware Description
2022-06-25
189
5
BMC management network
port and management serial
port (BMC_GE/COM/J2038)
6
USB 3.0 port (USB 3.0
CONN/J17)
7
LCD connector (LCD
CONN/J9)
8
OCP 3.0 network adapter
connector (OCP1
CONN/J108)
9
Built-in USB 3.0 connector
(INNER USB 3.0/J110)
10
VGA port (VGA
CONN/J2037)
11
Screw-in RAID controller
card connector (RAID
CARD/J86)
12
TPM/TCM connector (J10)
13
SATA connector 2
(SATA2/J2)
14
mini-SAS HD connector C
(MINIHD PORTC/J4)
15
mini-SAS HD connector B
(MINIHD PORTB/J5)
16
Rear-drive backplane power
connector 1 (REAR BP
PWR1/J64)
17
SATA connector 1
(SATA1/J1)
18
mini-SAS HD connector A
(MINIHD PORTA/J6)
19
NC-SI connector (NCSI
CONN/J114)
20
Cell battery holder (U9)
21
Built-in PCIe slot (PCIe
SLOT7/J2036)
22
Fan module 4 connector
(FAN4/J98)
23
VROC key connector (Soft
RAID KEY/J3)
a
24
Fan module 3 connector
(FAN3/J95)
25
Intrusion sensor connector
(INTRUDER CONN/S1)
26
Low-speed signal connector
for the front-drive backplane
(FRONT HDD BP/J75)
27
Fan module 2 connector
(FAN2/J91)
28
Fan module 1 connector
(FAN1/J67)
29
Left mounting ear connector
(LCID BOARD/J106)
30
Power connector for the
built-in-drive backplane
(INNER HDD PWR/J22)
31
Low-speed signal connector
for the built-in-drive
backplane (INNER HDD
BP/J27)
32
Power connector for the
front-drive backplane (HDD
BP PWR1/J88)
33
Rear-drive backplane power
connector 2 (REAR BP
PWR2/J20)
34
CPU2 LP Slimline 4
connector (SLIMLINE4/J12)
35
CPU2 LP Slimline 3
connector (SLIMLINE3/J85)
36
PSU 2 connector (PSU2/J56)
37
PSU 1 connector (PSU1/J28)
38
Rear 4 x 2.5" drive backplane
low-speed signal connector
