FusionServer 2288H V6 Server
Technical White Paper
A Appendix
2022-06-25
223
Figure A-8 SN example
Table A-5 SN description
No.
Description
1
ESN ID (two characters), which can only be 21.
2
Material ID (eight characters), that is, the processing code.
3
Vendor code (two characters), that is, the code of the processing place.
4
Year and month (two characters).
⚫
The first character indicates the year.
− Digits 1 to 9 indicate years 2001 to 2009, respectively.
− Letters A to H indicate years 2010 to 2017, respectively.
− Letters J to N indicate years 2018 to 2022, respectively.
− Letters P to Y indicate years 2023 to 2032, respectively.
NOTE
The years from 2010 are represented by upper-case letters excluding I, O, and Z
because the three letters are similar to the digits 1, 0, and 2.
⚫
The second character indicates the month.
− Digits 1 to 9 indicate January to September, respectively.
− Letters A to C indicate October to December, respectively.
5
Serial number (six digits).
6
RoHS compliance (one character). Y indicates RoHS compliant.
7
Internal model, that is, product name.
A.3 Operating Temperature Limitations
A.3.1 2288H V6-32DIMM
Table A-6 Operating temperature limitations
Configurat
ion
Maximum
Operating
Temperatu
re 30°C
(86°F)
Maximum
Operating
Temperatu
re 35°C
(95°F)
Maximum
Operating
Temperatu
re 40°C
(104°F)
Maximum
Operating
Temperatu
re 45°C
(113°F)
Maximum
Operating
Temperatu
re 50°C
(122°F)

xFusion Digital Technologies FusionServer 2288H V6 Specifications

General

Processor	Intel Xeon Scalable processors
Max Processors	2
Form Factor	2U
Memory	Up to 3TB
Memory Slots	32
Storage	Up to 12x 3.5" or 24x 2.5" drives
RAID Support	RAID 0, 1, 10, 5, 50, 6, or 60
Network	Dual 10GbE ports
Expansion Slots	Up to 7
PCIe Slots	7
Power Supply	Redundant 550W/800W/1200W
