FusionServer 2288H V6 Server
Technical White Paper
A Appendix
2022-06-25
242
A.6 Sensor List
A.6.1 2288H V6-32DIMM
Sensor
Description
Component
Inlet Temp
Air inlet temperature
Right mounting ear
Outlet Temp
Air outlet temperature
BMC card
PCH Temp
PCH bridge temperature
Mainboard
CPUN Core Rem
CPU core temperature
CPUN
N indicates the CPU
number. The value is 1 or 2.
CPUN DTS
Difference between the
real-time CPU temperature
and the core CPU
temperature threshold
CPUN
N indicates the CPU
number. The value is 1 or 2.
CPUN Margin
Difference between the
real-time CPU temperature
and the CPU Tcontrol
threshold
CPUN
N indicates the CPU
number. The value is 1 or 2.
CPUN VDDQ Temp
CPU VDDQ temperature
Mainboard
N indicates the CPU
number. The value is 1 or 2.
CPUN VRD Temp
CPU VRD temperature
Mainboard
N indicates the CPU
number. The value is 1 or 2.
CPUN MEM Temp
CPU memory module
temperature
Memory module
corresponding to CPU N
N indicates the CPU
number. The value is 1 or 2.
CPUN 12V
12 V voltage supplied by the
mainboard to the CPU
Mainboard
N indicates the CPU
number. The value is 1 or 2.
Riser 12V
12 V voltage supplied by the
mainboard to the riser card
Mainboard
Disk BP 12V
12 V voltage supplied by the
mainboard to the drive
backplane
Mainboard
CPUN DDR VDDQ
1.2 V memory module
voltage
Mainboard
N indicates the CPU
number. The value is 1 or 2.
CPUN DDR VDDQ2
1.2 V memory module
Mainboard
