FusionServer 2288H V6 Server
Technical White Paper
A Appendix
2022-06-25
245
Sensor
Description
Component
LCD Status
LCD health status
LCD
LCD Presence
LCD presence
LCD
PS Redundancy
Redundancy failure due to
PSU removal
Power supply unit (PSU)
PSN Status
PSU status
PSU N
N indicates the PSU
number. The value is 1 or 2.
PSN Fan Status
PSU fan fault status
PSU N
N indicates the PSU
number. The value is 1 or 2.
PSN Temp Status
PSU presence
PSU N
N indicates the PSU
number. The value is 1 or 2.
DISK$
Disk status
Drive
PCIe RAID$ Temp
Temperature of the PCIe
RAID controller card
PCIe RAID controller card
M2 Temp(PCIe$)
Maximum temperature of all
M.2 drives of the RAID
controller card
PCIe RAID controller card
RAID Temp
Temperature of the RAID
controller card
RAID controller card
RAID Status
RAID controller card health
status
RAID controller card
RAID PCIE ERR
Health status of the RAID
controller card in fault
diagnosis
RAID controller card
IB$ Temp
IB NIC temperature
IB card
PCIe$ OP Temp
PCIe card optical module
temperature
PCIe card
PCIe NIC$ Temp
PCIe card chip temperature
PCIe card
PCIe FC$ Temp
PCIe card chip temperature
PCIe card
RAID Card BBU
RAID controller card BBU
BBU supercapacitor of
RAID controller card
FPGA$ Temp
FPGA card temperature
PCIe card
FPGA$ DDR Temp
FPGA card memory
temperature
PCIe card
FPGA$ Power
FPGA card power
PCIe card
