xFusion Digital Technologies FusionServer 2288H V6 User Manual

FusionServer 2288H V6 Server
Technical White Paper
5 Hardware Description
2022-06-25
40
Table 5-5 Memory channels
CPU
Channel
Memory Slot
CPU 1
A (primary)
DIMM000(A)
A
DIMM001(I)
B (primary)
DIMM010(B)
B
DIMM011(J)
C (primary)
DIMM020(C)
C
DIMM021(K)
D (primary)
DIMM030(D)
D
DIMM031(L)
E (primary)
DIMM040(E)
E
DIMM041(M)
F (primary)
DIMM050(F)
F
DIMM051(N)
G (primary)
DIMM060(G)
G
DIMM061(O)
H (primary)
DIMM070(H)
H
DIMM071(P)
CPU2
A (primary)
DIMM100(A)
A
DIMM101(I)
B (primary)
DIMM110(B)
B
DIMM111(J)
C (primary)
DIMM120(C)
C
DIMM121(K)
D (primary)
DIMM130(D)
D
DIMM131(L)
E (primary)
DIMM140(E)
E
DIMM141(M)
F (primary)
DIMM150(F)
F
DIMM151(N)
G (primary)
DIMM160(G)
G
DIMM161(O)

xFusion Digital Technologies FusionServer 2288H V6 Specifications

General

Processor	Intel Xeon Scalable processors
Max Processors	2
Form Factor	2U
Memory	Up to 3TB
Memory Slots	32
Storage	Up to 12x 3.5" or 24x 2.5" drives
RAID Support	RAID 0, 1, 10, 5, 50, 6, or 60
Network	Dual 10GbE ports
Expansion Slots	Up to 7
PCIe Slots	7
Power Supply	Redundant 550W/800W/1200W
