xFusion Digital Technologies FusionServer 2288H V6 User Manual

FusionServer 2288H V6 Server
Technical White Paper
5 Hardware Description
2022-06-25
63
Configuration
Front Drive
Rear Drive
Built-in Drive
Drive
Management
Mode
support
only
NVMe
drives
a
.
12 x 3.5" drive
pass-through
configuration 3
(4 x NVMe)
⚫
Front drive:
12 x 3.5"
− Slots 0 to
7 support
only
SAS/SAT
A drives.
− Slots 8 to
11
support
SAS/SAT
A/NVMe
drives.
⚫
I/O module
1: 2 x 2.5"
− Slots 40
and 41
support
only
SAS/SAT
A drives.
⚫
I/O module
2: 2 x 2.5"/2
x 3.5"
− Slots 42
and 43
support
only
SAS/SAT
A drives.
⚫
I/O module
3: 4 x 2.5"
− Slots 44
to 47
support
only
NVMe
drives
a
.
-
⚫
SAS/SATA
drive: 1 x
PCIe RAID
controller
card
⚫
NVMe
drive: CPU
⚫
a: The server with CPU 2 supports NVMe drives, but the server with a single CPU does
not support NVMe drives.
⚫
Contact your local sales representative or see "Search Parts" in the Compatibility
Checker to determine the components to be used.
