FMC XM105 Debug Card User Guide www.xilinx.com 23
UG537 (v1.2) September 24, 2010
Board Technical Description
10. Connector J1
This 40-position connector provides an interface from the XM105 to 40 single-ended
signals on the board’s FMC LPC or FMC HPC interface. Connections between the
mezzanine FMC HPC and J1 are defined in Table 1-10.
Table 1-10: Mezzanine FMC HPC J17 to Connector J1 Pin Assignments
FMC HPC
Connector
J17 Pin
Signal Name
J1
Connector
(Odd Pins)
FMC HPC
Connector
J17 Pin
Signal Name
J1
Connector
(Even Pins)
G6 FMC_LA00_CC_P
(1)
1 C14 FMC_LA10_P 2
G7 FMC_LA00_CC_N
(1)
3 C15 FMC_LA10_N 4
D8 FMC_LA01_CC_P
(1)
5 H16 FMC_LA11_P 6
D9 FMC_LA01_CC_N
(1)
7 H17 FMC_LA11_N 8
H7 FMC_LA02_P 9 G15 FMC_LA12_P 10
H8 FMC_LA02_N 11 G16 FMC_LA12_N 12
G9 FMC_LA03_P 13 D17 FMC_LA13_P 14
G10 FMC_LA03_N 15 D18 FMC_LA13_N 16
H10 FMC_LA04_P 17 C18 FMC_LA14_P 18
H11 FMC_LA04_N 19 C19 FMC_LA14_N 20
D11 FMC_LA05_P 21 H19 FMC_LA15_P 22
D12 FMC_LA05_N 23 H20 FMC_LA15_N 24
C10 FMC_LA06_P 25 G18 FMC_LA16_P 26
C11 FMC_LA06_N 27 G19 FMC_LA16_N 28
H13 FMC_LA07_P 29 D20 FMC_LA17_CC _P
(1)
30
H14 FMC_LA07_N 31 D21 FMC_LA17_CC _N
(1)
32
G12 FMC_LA08_P 33 C22 FMC_LA18_CC _P
(1)
34
G13 FMC_LA08_N 35 C23 FMC_LA18_CC _N
(1)
36
D14 FMC_LA09_P 37 H22 FMC_LA19_P 38
D15 FMC_LA09_N 39 H23 FMC_LA19_N 40
Notes:
1. Signal names with “_CC_” can be connected to FPGA clock capable pins on the board. See Xilinx board user guides for
additional information.
