18 www.xilinx.com FMC XM105 Debug Card User Guide
UG537 (v1.2) September 24, 2010
Chapter 1: XM105
See the Xilinx board user guides and schematics for a description of features provided by
LPC and/or HPC interfaces contained on the board, including power supply
specifications, FPGA banking connectivity, and FPGA pin assignments.
• For SP601 LPC interface, see U
G518 SP601 Hardware User Guide
• For SP605 LPC interface, see U
G526 SP605 Hardware User Guide
• For ML605 LPC and HPC interfaces, see U
G534 ML605 Hardware User Guide
See the VITA57.1 Specification at www.vita.com/fmc.html
for additional information on
FMC.
2. Connector J6 6-pin Header
This 3 x 2 position header provides a means to manually configure XM105 voltage
connections provided to the J16 connector by configuring the shunts on the XM105. Shunts
are not provided with the kit.
For 3.3V power:
Install a shunt on connector J6-1 to J6-3 and another shunt on connector J6-2 to J6-4 to
connect the board 3.3V power to the HDR_POWER net on connector J16 pins 1 and 2.
For VADJ power:
Install a shunt on connector J6-3 to J6-5 and another shunt on connector J6-4 to J6-6
connect the board VADJ power to the HDR_POWER net on connector J16 pins 1 and 2.
Xilinx boards provide fixed 2.5V power to the VADJ pins of the FMC connector.
