Chapter 1: XM105
11. Connector J3
This 40-position connector provides an interface from the XM105 to 40 single-ended
signals on the board’s FMC HPC interface. Connections between the mezzanine FMC HPC
and connector J3 are defined in Table 1-11. This interface can only be used when installed
on a board supporting the FMC HPC interface.
Table 1-11: Mezzanine FMC HPC J17 to Connector J3 Pin Assignments
FMC HPC
Connector
J17 Pin
Signal Name
J3
Connector
(Odd Pins)
FMC HPC
Connector
J17 Pin
Signal Name
J3 Connector
(Even Pins)
F4 FMC_HA00_CC _P
(1)
1 K13 FMC_HA10_P 2
F5 FMC_HA00_CC _N
(1)
3 K14 FMC_HA10_N 4
E2 FMC_HA01_CC _P
(1)
5 J12 FMC_HA11_P 6
E3 FMC_HA01_CC _N
(1)
7 J13 FMC_HA11_N 8
K7 FMC_HA02_P 9 F13 FMC_HA12_P 10
K8 FMC_HA02_N 11 F14 FMC_HA12_N 12
J6 FMC_HA03_P 13 E12 FMC_HA13_P 14
J7 FMC_HA03_N 15 E13 FMC_HA13_N 16
F7 FMC_HA04_P 17 J15 FMC_HA14_P 18
F8 FMC_HA04_N 19 J16 FMC_HA14_N 20
E6 FMC_HA05_P 21 F16 FMC_HA15_P 22
E7 FMC_HA05_N 23 F17 FMC_HA15_N 24
K10 FMC_HA06_P 25 E15 FMC_HA16_P 26
K11 FMC_HA06_N 27 E16 FMC_HA16_N 28
J9 FMC_HA07_P 29 K16 FMC_HA17_CC _P
(1)
30
J10 FMC_HA07_N 31 K17 FMC_HA17_CC _N
(1)
32
F10 FMC_HA08_P 33 J18 FMC_HA18_P 34
F11 FMC_HA08_N 35 J19 FMC_HA18_N 36
E9 FMC_HA09_P 37 F19 FMC_HA19_P 38
E10 FMC_HA09_N 39 F20 FMC_HA19_N 40
Notes:
1. Signal names with “_CC_” can be connected to FPGA clock capable pins on the board. See Xilinx board user guides for
additional information.
