Chapter 1: XM105
Quick Start
System Requirements
Hardware
Table 1-1 lists the boards validated to support the XM105. Both low pin count (LPC) and
high pin count (HPC) FMC interfaces are supported. The SP601 and SP605 boards provide
a single FMC LPC interface. The ML605 board provides one FMC LPC and one FMC HPC
interface. The XM105 contains an HPC connector that mates with either LPC or HPC
connectors.
Software
Example designs that use this hardware are not provided.
Package Contents
The following items are included in the HW-FMC-XM105-G shipment:
• XM105
• Four (4) mounting screws
•Two (2) standoffs
• Welcome letter
Board documentation, schematics, and PCB design files are available at
www.xilinx.com/fmc
.
Necessary Equipment
• Small Phillips screwdriver to secure the XM105 to the board
• PC with Internet access to download documentation, board files, and schematics
Table 1-1: FMC Supported Boards
Xilinx Platform Part Number
FMC LPC
Support
FMC HPC
Support
Spartan-6 FPGA SP601 Evaluation Kit EK-S6-SP601-G 1 0
Spartan-6 FPGA SP605 Evaluation Kit EK-S6-SP605-G 1 0
Virtex-6 FPGA ML605 Evaluation Kit EK-V6-ML605-G 1 1
Notes:
While every effort has been made to comply with the FPGA Mezzanine Card Specification, Xilinx cannot
claim nor assume full compliance with the FMC/VITA-57-1 specification. Consequently, Xilinx cannot
claim nor support the usage of the XM105 on any other FMC (VITA-57.1) board.
Xilinx FMC cards are generally designed to implement expanded functionality for supported Xilinx
evaluation boards (SP601, SP605, or ML605) and thus might exceed the FMC card outline dimensions
discussed in the Single Width FMC Module Mechanical section of the FMC/VITA-57-1 specification.
Therefore, Xilinx FMC cards might not physically fit in a non-Xilinx evaluation board environment.
