Xilinx KC705 User Manual

KC705 Evaluation Board 11
UG810 (v1.8) March 20, 2018 www.xilinx.com
Chapter 1: KC705 Evaluation Board Features
12 GTX Transceivers Embedded within FPGA U1 9
13 P1 PCI Express Edge Connector 8-lane card edge connector 21
14 P5 SFP/SFP+ Connector Molex 74441-0010 22
15 U37 10/100/1000 Tri-Speed Ethernet
PHY
Marvell M88E1111-BAB1C000 25
16 U2 SGMII GTX Transceiver Clock
Generator
ICS ICS84402IAGI-01LF 23
17 J6, U12 USB-to-UART Bridge Silicon Labs CP2103GM bridge
(back side of board) and min-B
receptacle (front side of board)
27
18 P6, U65 HDMI Video Output Molex 500254-1927, Analog
Devices ADV7511KSTZ-P
34, 33
19 J31 LCD Character Display 2 x 7 0.1 in male pin header 30
20 U49 I2C Bus Switch, page 52 TI PCA9548ARGER 32
21 DS11 - DS13 Ethernet PHY Status LEDs EPHY status LED, dual green 25
34 DS14, DS20 -
DS24
Status LEDs Status LEDs, green 29
22 DS1 - DS4,
Ds10,
DS25 - DS27
User GPIO LEDs GPIO LEDs, green 29
23 SW2 – SW6 User Pushbuttons E-Switch TL3301EP100QG 29
24 SW11 GPIO DIP Switch C and K 4-pole, SDA05H1SBD 29
25 SW8 Rotary Switch Panasonic EVQ-WK4001 29
26 J13, J14 GPIO SMA Connectors Rosenberger 32K10K-400L5 23
27 SW15 Power On/Off Slide Switch SW15 C and K 1201M2S3AQE2 35
28 SW14 FPGA_PROG_B Pushbutton SW14
(Active-Low)
E-Switch TL3301EP100QG 29
29 SW13 Configuration Mode and Upper
Linear Flash Address Switch
(SW13)
5-pole C and K SDA05H1IBD 27
30 J22 HPC Connector J22 Samtec ASP_134486_01 16-19
31 J2 LPC Connector J2 Samtec ASP_134603_01 20
32 U55, U21,
U103, U17,
U56, U104,
U105, U89,
U106, U99,
U71, U62,
U17, U18, U33
Power Management (voltage
regulators front side of board,
controllers back side of board)
TI UCD9248PFC controllers in
conjunction with various
regulators
35-46
33 J46 XADC Header 2X10 0.1" male header 31
Table 1-1: KC705 Board Component Descriptions (Cont’d)
Callout
Reference
Designator
Component Description Notes
Schematic
0381397
Page Number
