Xilinx KC705 User Manual

KC705 Evaluation Board 83
UG810 (v1.8) March 20, 2018 www.xilinx.com
Appendix A
Default Switch and Jumper Settings
DIP Switch SW11 User GPIO
See Figure 1-2, page 10 Item 24 for location of SW11. Default settings are shown in
Figure A-1 and details are listed in Table A-1.
X-Ref Target - Figure A-1
Figure A-1: SW11 Default Settings
Table A-1: SW11 Default Switch Settings
Position Function Default
1 GPIO_DIP_SW3 Off
2 GPIO_DIP_SW2 Off
3 GPIO_DIP_SW1 Off
4 GPIO_DIP_SW0 Off
UG810_aA_01_03214
GPIO DIP SW
1
SW11
OFF Position = 0
ON Position = 1
234
Send Feedback
