KC705 Evaluation Board 40
UG810 (v1.8) March 20, 2018 www.xilinx.com
Chapter 1: KC705 Evaluation Board Features
For more information refer to 7 Series FPGAs GTX Transceivers User Guide (UG476) [Ref 12]
and 7 Series FPGAs Integrated Block for PCI Express User Guide (AXI) (PG054) [Ref 13].
MGTXRXP2_116_P6 P6 PCIE_RX1_P B19 PETp1 GTXE2_CHANNEL_X0Y6
MGTXRXN2_116_P5 P5 PCIE_RX1_N B20 PETn1 GTXE2_CHANNEL_X0Y6
MGTXTXP3_116_L4 L4 PCIE_TX0_P A16 PERp0 GTXE2_CHANNEL_X0Y7
MGTXTXN3_116_L3 L3 PCIE_TX0_N A17 PERn0 GTXE2_CHANNEL_X0Y7
MGTXRXP3_116_M6 M6 PCIE_RX0_P B14 PETp0 GTXE2_CHANNEL_X0Y7
MGTXRXN3_116_M5 M5 PCIE_RX0_N B15 PETn0 GTXE2_CHANNEL_X0Y7
MGTREFCLK0P_116_L8 L8 SI5326_OUT_C_P MGT_BANK_116
MGTREFCLK0N_116_L7 L7 SI5326_OUT_C_N MGT_BANK_116
MGTREFCLK1P_116_N8 N8 FMC_LPC_GBTCLK0_M2C_C_P MGT_BANK_116
MGTREFCLK1N_116_N7 N7 FMC_LPC_GBTCLK0_M2C_C_N MGT_BANK_116
Table 1-13: GTX Quad 116 to PCIe Edge Connector Connections (Cont’d)
Quad 116 Pin Name
FPGA
Pin (U1)
Schematic Net Name
PCIe Edge
Connector
Pin
PCIe
Edge in
Name
FFG900 Placement
Send Feedback
