Xilinx KC705 User Manual

KC705 Evaluation Board 70
UG810 (v1.8) March 20, 2018 www.xilinx.com
Chapter 1: KC705 Evaluation Board Features
G3 FMC_LPC_CLK1_M2C_N LVDS AH29 H2 FMC_LPC_PRSNT_M2C_B LVCMOS25
G6 FMC_LPC_LA00_CC_P LVCOMS1
8
AD23 H4 FMC_LPC_CLK0_M2C_P LVDS AF22
G7 FMC_LPC_LA00_CC_N LVCOMS1
8
AE24 H5 FMC_LPC_CLK0_M2C_N LVDS AG23
G9 FMC_LPC_LA03_P LVDS AG20 H7 FMC_LPC_LA02_P LVDS AF20
G10 FMC_LPC_LA03_N LVDS AH20 H8 FMC_LPC_LA02_N LVDS AF21
G12 FMC_LPC_LA08_P LVDS AJ22 H10 FMC_LPC_LA04_P LVDS AH21
G13 FMC_LPC_LA08_N LVDS AJ23 H11 FMC_LPC_LA04_N LVDS AJ21
G15 FMC_LPC_LA12_P LVDS AA20 H13 FMC_LPC_LA07_P LVDS AG25
G16 FMC_LPC_LA12_N LVDS AB20 H14 FMC_LPC_LA07_N LVDS AH25
G18 FMC_LPC_LA16_P LVDS AC22 H16 FMC_LPC_LA11_P LVDS AE25
G19 FMC_LPC_LA16_N LVDS AD22 H17 FMC_LPC_LA11_N LVDS AF25
G21 FMC_LPC_LA20_P LVDS AF26 H19 FMC_LPC_LA15_P LVDS AC24
G22 FMC_LPC_LA20_N LVDS AF27 H20 FMC_LPC_LA15_N LVDS AD24
G24 FMC_LPC_LA22_P LVDS AJ27 H22 FMC_LPC_LA19_P LVDS AJ26
G25 FMC_LPC_LA22_N LVDS AK28 H23 FMC_LPC_LA19_N LVDS AK26
G27 FMC_LPC_LA25_P LVDS AC26 H25 FMC_LPC_LA21_P LVDS AG27
G28 FMC_LPC_LA25_N LVDS AD26 H26 FMC_LPC_LA21_N LVDS AG28
G30 FMC_LPC_LA29_P LVDS AE28 H28 FMC_LPC_LA24_P LVDS AG30
G31 FMC_LPC_LA29_N LVDS AF28 H29 FMC_LPC_LA24_N LVDS AH30
G33 FMC_LPC_LA31_P LVDS AD29 H31 FMC_LPC_LA28_P LVDS AE30
G34 FMC_LPC_LA31_N LVDS AE29 H32 FMC_LPC_LA28_N LVDS AF30
G36 FMC_LPC_LA33_P LVDS AC29 H34 FMC_LPC_LA30_P LVDS AB29
G37 FMC_LPC_LA33_N LVDS AC30 H35 FMC_LPC_LA30_N LVDS AB30
G39 VADJ H37 FMC_LPC_LA32_P LVDS Y30
H38 FMC_LPC_LA32_N LVDS AA30
H40 VADJ
Table 1-29: LPC Connections, J2 to FPGA U1 (Cont’d)
J2 Pin Schematic Net Name
I/O
Standard
U1
FPGA
Pin
J2
Pin
Schematic Net Name
I/O
Standard
U1
FPGA
Pin
