MicroBlaze Development Kit Spartan-3E 1600 Edition User Guide 85
UG257 (v1.1) December 5, 2007 www.xilinx.com
StrataFlash Connections
R
Table 1 1 -1: FPGA-to-StrataFlash Connections
Category
StrataFlash
Signal Name
FPGA Pin
Number Function
Address
SF_A24 A11 Shared with XC2C64A CPLD. The CPLD
actively drives these pins during FPGA
configuration, as described in Chapter 16,
“XC2C64A CoolRunner-II CPLD”. Also
connects to FPGA user-I/O pins. SF_A24 is the
same as FX2 connector signal FX2_IO<32>.
SF_A23 N11
SF_A22 V12
SF_A21 V13
SF_A20 T12
SF_A19 V15 Connects to FPGA pins A[19:0] to support the
BPI configuration.
SF_A18 U15
SF_A17 T16
SF_A16 U18
SF_A15 T17
SF_A14 R18
SF_A13 T18
SF_A12 L16
SF_A11 L15
SF_A10 K13
SF_A9 K12
SF_A8 K15
SF_A7 K14
SF_A6 J17
SF_A5 J16
SF_A4 J15
SF_A3 J14
SF_A2 J12
SF_A1 J13
SF_A0 H17
