Xilinx RocketIO User Manual

100 www.xilinx.com RocketIO™ Transceiver User Guide
UG024 (v3.0) February 22, 2007
Chapter 2: Digital Design Considerations
R
-- is, upon an asserted RXREALIGN
-- or RXCOMMADET.
PROCESS (usrclk2)
BEGIN
IF (usrclk2'EVENT AND usrclk2 = '1') THEN
IF (rxreset = '1') THEN
wait_to_sync <= “1111”;
count <= '0';
ELSE
IF (rxrealign = '1') THEN
wait_to_sync <= “1111”;
count <= '1';
ELSE
IF (count = '1') THEN
IF (wait_to_sync /= “0000”) THEN
wait_to_sync <= wait_to_sync - “0001”;
END IF;
END IF;
IF (rxcommadet = '1') THEN
count <= '1';
END IF;
END IF;
END IF;
END IF;
END PROCESS;
-- This process maintains output sync, which
-- indicates when outgoing aligned_data
-- should be properly aligned, with the comma
-- in aligned_data[31:24]. Output aligned_data is
-- considered to be in sync when a comma is seen
-- on rxdata (as indicated
-- by rxchariscomma3 or 1) after the counter
-- wait_to_sync has reached 0, indicating
-- that commas seen by the comma detection circuit
-- have had time to propagate to
-- aligned_data after initialization of the elastic buffer.
PROCESS (usrclk2)
BEGIN
IF (usrclk2'EVENT AND usrclk2 = '1') THEN
IF ((rxreset OR rxrealign) = '1') THEN
sync_hold <= '0';
ELSE
IF (wait_to_sync = “0000”)THEN
IF ((rxchariscomma3 OR rxchariscomma1) = '1') THEN
sync_hold <= '1';
END IF;
END IF;
END IF;
END IF;
END PROCESS;
-- This process generates aligned_data with commas
-- aligned in [31:24],
-- assuming that incoming commas are aligned
-- to [31:24] or [15:8].
-- Here, you could add code to use ENPCOMMAALIGN and
-- ENMCOMMAALIGN to enable a move back into the
Product Not Recommended for New Designs

Xilinx RocketIO Specifications

General

Form Factor	Integrated into Xilinx FPGAs and SoCs
Technology	CMOS
Category	Transceiver
Protocol Support	Aurora, Ethernet, CPRI
Package	Integrated into FPGA/SoC package
Data Rate	Up to 28.05 Gbps
Signal Integrity	Integrated equalization, pre-emphasis, and decision feedback equalization (DFE)
