Chapter 1: RocketIO Transceiver Overview
R
Modifiable Primitives
As shown in Table 1-7 and Table 1-8, only certain attributes are modifiable for any
primitive. These attributes help to define the protocol used by the primitive. Only the
GT_CUSTOM primitive allows the user to modify all of the attributes to a protocol not
supported by another transceiver primitive. This allows for complete flexibility. The other
primitives allow modification of the analog attributes of the serial data lines and several
channel-bonding values.
Table 1-7: Default Attribute Values: GT_AURORA, GT_CUSTOM, GT_ETHERNET
Attribute
Default
GT_AURORA
Default
GT_CUSTOM
(1)
Default
GT_ETHERNET
ALIGN_COMMA_MSB FALSE FALSE FALSE
CHAN_BOND_LIMIT 16 16 1
CHAN_BOND_MODE OFF
(2)
OFF OFF
CHAN_BOND_OFFSET 8 8 0
CHAN_BOND_ONE_SHOT FALSE
(2)
FALSE TRUE
CHAN_BOND_SEQ_1_1 00101111100 00000000000 00000000000
CHAN_BOND_SEQ_1_2 00000000000 00000000000 00000000000
CHAN_BOND_SEQ_1_3 00000000000 00000000000 00000000000
CHAN_BOND_SEQ_1_4 00000000000 00000000000 00000000000
CHAN_BOND_SEQ_2_1 00000000000 00000000000 00000000000
CHAN_BOND_SEQ_2_2 00000000000 00000000000 00000000000
CHAN_BOND_SEQ_2_3 00000000000 00000000000 00000000000
CHAN_BOND_SEQ_2_4 00000000000 00000000000 00000000000
CHAN_BOND_SEQ_2_USE FALSE FALSE FALSE
CHAN_BOND_SEQ_LEN 1 1 1
CHAN_BOND_WAIT 887
CLK_COR_INSERT_IDLE_FLAG FALSE
(2)
FALSE FALSE
(2)
CLK_COR_KEEP_IDLE FALSE
(2)
FALSE FALSE
(2)
CLK_COR_REPEAT_WAIT 1
(2)
11
(2)
CLK_COR_SEQ_1_1 00111110111 00000000000 00110111100
CLK_COR_SEQ_1_2 00111110111 00000000000 00001010000
CLK_COR_SEQ_1_3 00111110111
(5)
00000000000 00000000000
CLK_COR_SEQ_1_4 00111110111
(5)
00000000000 00000000000
CLK_COR_SEQ_2_1 00000000000 00000000000 00000000000
Product Not Recommended for New Designs
