RocketIO™ Transceiver User Guide www.xilinx.com 95
UG024 (v3.0) February 22, 2007
Other Important Design Notes
R
32-bit Alignment Design
The following example code illustrates one way to create the logic to properly align 32-bit
wide data with a comma in bits [31:24] For brevity, most status bits are not included in this
example design; however, these should be shifted in the same manner as RXDATA and
RXCHARISK.
Note that when using a 40-bit data path (8B/10B bypassed), a similar realignment scheme
may be used, but it cannot rely on RXCHARISCOMMA for comma detection.
Verilog
/*********************************************************************
*
* XILINX IS PROVIDING THIS DESIGN, CODE, OR INFORMATION “AS IS”
* AS A COURTESY TO YOU, SOLELY FOR USE IN DEVELOPING PROGRAMS AND
* SOLUTIONS FOR XILINX DEVICES. BY PROVIDING THIS DESIGN, CODE,
* OR INFORMATION AS ONE POSSIBLE IMPLEMENTATION OF THIS FEATURE,
* APPLICATION OR STANDARD, XILINX IS MAKING NO REPRESENTATION
* THAT THIS IMPLEMENTATION IS FREE FROM ANY CLAIMS OF INFRINGEMENT,
* AND YOU ARE RESPONSIBLE FOR OBTAINING ANY RIGHTS YOU MAY REQUIRE
* FOR YOUR IMPLEMENTATION. XILINX EXPRESSLY DISCLAIMS ANY
* WARRANTY WHATSOEVER WITH RESPECT TO THE ADEQUACY OF THE
* IMPLEMENTATION, INCLUDING BUT NOT LIMITED TO ANY WARRANTIES OR
* REPRESENTATIONS THAT THIS IMPLEMENTATION IS FREE FROM CLAIMS OF
* INFRINGEMENT, IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
* FOR A PARTICULAR PURPOSE.
*
* (c) Copyright 2002 Xilinx Inc.
* All rights reserved.
*
*********************************************************************/
// Virtex-II Pro RocketIO comma alignment module
//
// This module reads RXDATA[31:0] from a RocketIO transceiver
// and copies it to
// its output, realigning it if necessary so that commas
// are aligned to the MSB position
// [31:24]. The module assumes ALIGN_COMMA_MSB is TRUE,
// so that the comma
// is already aligned to [31:24] or [15:8].
//
// Outputs
//
// aligned_data[31:0] -- Properly aligned 32-bit ALIGNED_DATA
// sync -- Indicator that aligned_data is properly aligned
// aligned_rxisk[3:0] - properly aligned 4 bit RXCHARISK
// Inputs - These are all RocketIO inputs or outputs
// as indicated:
//
// usrclk2 -- RXUSRCLK2
// rxreset -- RXRESET
// rxisk[3:0] RXCHARISK[3:0]
// rxdata[31:0] RXDATA[31:0] -- (commas aligned to
// [31:24] or [15:8])
// rxrealign -- RXREALIGN
// rxcommadet -- RXCOMMADET
Product Not Recommended for New Designs
