Xilinx VCU118 User Manual

VCU118 Board User Guide 105
UG1224 (v1.0) December 15, 2016
www.xilinx.com
Chapter 3: Board Component Descriptions
J22 Sections Y/Z Connections to FPGA U1
Y2 FMCP_HSPC_DP23_C2M_P LVDS AV42
Z1 FMCP_HSPC_Z_PRSNT_M2C_B LVCMOS18 AM29
Y3 FMCP_HSPC_DP23_C2M_N LVDS AV43 Z4 FMCP_HSPC_DP22_C2M_P LV DS AY4 2
Y6 FMCP_HSPC_DP21_C2M_P LVDS BB42 Z5 FMCP_HSPC_DP22_C2M_N LVDS AY43
Y7 FMCP_HSPC_DP21_C2M_N LVDS BB43 Z8 FMCP_HSPC_DP20_C2M_P L VDS BD 42
Y10 FMCP_HSPC_DP10_M2C_P LVDS AE45 Z9 FMCP_HSPC_DP20_C2M_N LVDS BD43
Y11 FMCP_HSPC_DP10_M2C_N LVDS AE46 Z12 FMCP_HSPC_DP11_M2C_P LVDS AD43
Y14 FMCP_HSPC_DP12_M2C_P LVDS AC45 Z13 FMCP_HSPC_DP11_M2C_N LVDS AD44
Y15 FMCP_HSPC_DP12_M2C_N LVDS AC46 Z16 FMCP_HSPC_DP13_M2C_P LVDS AB43
Y18 FMCP_H SPC_DP14_M2C_P LVDS AA45 Z17 F MCP_HSPC_DP13_M2C_N LVDS AB44
Y19 FMCP_HSPC_DP14_M2C_N LVDS AA46 Z20 FMCP_HSPC_G BTCLK5_M2C_P LVDS AN40
Y22 FMCP_HSPC_DP15_M2C_P LVDS Y43 Z21 FMCP_HSPC_GBTCLK5_M2C_N LVDS AN41
Y23 FMCP_HSPC_DP15_M2C_N LVDS Y44 Z24 FMCP_HSPC_DP10_C2M_P LVDS AG40
Y26 FMCP_HSPC_DP11_C2M_P LVDS AE40 Z25 FMCP_HSPC_DP10_C2M_N LVDS AG41
Y27 FMCP_HSPC_DP11_C2M_N LVDS AE41 Z28 FMCP_HSPC_DP12_C2M_P LVDS AC40
Y30 FMC P_HSPC_DP13_C2 M_P LVDS AA40 Z29 FMCP_HS PC_DP12_C2M_N LVDS AC41
Y31 FMCP_HSPC_DP13_C2M_N LVDS AA41 Z32 FMCP_HSPC_DP16_M2C_P LVDS L45
Y34 FMCP_HSPC_DP17_M2C_P LVDS J45 Z33 FMCP_HSPC_DP16_M2C_N LVDS L46
Y35 FMCP_HSPC_DP17_M2C_N LVDS J46 Z36 FMCP_HSPC_DP18_M2C_P LVDS G45
Y38 FMCP_HSPC_DP19_M2C_P LVDS E45 Z37 FMCP_HSPC_DP18_M2C_N LVDS G46
Y39 FMCP_HSPC_DP19_M2C_N LVDS E46 Z40 UTIL_3V3
