VCU118 Board User Guide 8
UG1224 (v1.0) December 15, 2016
www.xilinx.com
Chapter 1: Introduction
• Two Pmod 2x6 connectors (one male pin header, one right-angle receptacle)
• VITA 57.4 FMC+ HSPC connector J22
•VITA 57.1 FMC HPC1 connector J2
• Power management with PMBus voltage monitoring through Maxim power controllers
and GUI
• 10-bit 0.2 MSPS SYSMON analog-to-digital front end
• Configuration options:
°
BPI linear flash memory
°
Digilent USB configuration module
°
Platform cable USB II interface 2x7 2 mm connector
Board Specifications
Dimensions
Height: 6.927 inch (17.59 cm)
Thickness (±5%): 0.061 inch (0.1549 cm)
Length: 9.5 inch (24.13 cm)
Note:
A 3D model of this board is not available.
IMPORTANT: The VCU118 board height exceeds the standard 4.376 inch (11.15 cm) height of a PCI
Express
®
card.
Environmental
Temperature
Operating: 0°C to +45°C
Storage: -25°C to +60°C
Humidity
10% to 90% non-condensing
