Xilinx VCU118 User Manual

VCU118 Board User Guide 27
UG1224 (v1.0) December 15, 2016
www.xilinx.com
Chapter 3: Board Component Descriptions
AW31 DDR4_C2_DQ12 POD12_DCI C2 DQU4 U135
AW32 DDR4_C2_DQ13 POD12_DCI C8 DQU5 U135
AY32 DDR4_C2_DQ14 POD12_DCI D3 DQU6 U135
AY33 DDR4_C2_DQ15 POD12_DCI D7 DQU7 U135
BF30 DDR4_C2_DQS0_T DIFF_POD12_DCI G3 DQSL_T U135
BF31 DDR4_C2_DQS0_C DIFF_POD12_DCI F3 DQSL_C U135
AY34 DDR4_C2_DQS1_T DIFF_POD12_DCI B7 DQSU_T U135
BA34 DDR4_C2_DQS1_C DIFF_POD12_DCI A7 DQSU_C U135
BE32 DDR4_C2_DM0 POD12_DCI E7 DML_B/DBIL_B U135
BB31 DDR4_C2_DM1 POD12_DCI E2 DMU_B/DBIU_B U135
AV30 DDR4_C2_DQ16 POD12_DCI G2 DQL0 U136
AW30 DDR4_C2_DQ17 POD12_DCI F7 DQL1 U136
AU33 DDR4_C2_DQ18 POD12_DCI H3 DQL2 U136
AU34 DDR4_C2_DQ19 POD12_DCI H7 DQL3 U136
AT31 DDR4_C2_DQ20 POD12_DCI H2 DQL4 U136
AU32 DDR4_C2_DQ21 POD12_DCI H8 DQL5 U136
AU31 DDR4_C2_DQ22 POD12_DCI J3 DQL6 U136
AV31 DDR4_C2_DQ23 POD12_DCI J7 DQL7 U136
AR33 DDR4_C2_DQ24 POD12_DCI A3 DQU0 U136
AT34 DDR4_C2_DQ25 POD12_DCI B8 DQU1 U136
AT29 DDR4_C2_DQ26 POD12_DCI C3 DQU2 U136
AT30 DDR4_C2_DQ27 POD12_DCI C7 DQU3 U136
AP30 DDR4_C2_DQ28 POD12_DCI C2 DQU4 U136
AR30 DDR4_C2_DQ29 POD12_DCI C8 DQU5 U136
AN30 DDR4_C2_DQ30 POD12_DCI D3 DQU6 U136
AN31 DDR4_C2_DQ31 POD12_DCI D7 DQU7 U136
AU29 DDR4_C2_DQS2_T DIFF_POD12_DCI G3 DQSL_C U136
AV29 DDR4_C2_DQS2_C DIFF_POD12_DCI F3 DQSL_T U136
AP31 DDR4_C2_DQS3_T DIFF_POD12_DCI B7 DQSU_C U136
AP32 DDR4_C2_DQS3_C DIFF_POD12_DCI A7 DQSU_T U136
AV33 DDR4_C2_DM2 POD12_DCI E7 DML_B/DBIL_B U136
AR32 DDR4_C2_DM3 POD12_DCI E2 DMU_B/DBIU_B U136
BE34 DDR4_C2_DQ32 POD12_DCI G2 DQL0 U137
BF34 DDR4_C2_DQ33 POD12_DCI F7 DQL1 U137
Table 3-3: DDR4 Memory 80-bit I/F C2 to FPGA U1 Banks 40, 41, and 42 (Cont’d)
FPGA (U1)
Pin
Schematic Net Name I/O Standard
Component Memory
Pin # Pin Name Ref. Des.
