Xilinx VCU118 User Manual

VCU118 Board User Guide 84
UG1224 (v1.0) December 15, 2016
www.xilinx.com
Chapter 3: Board Component Descriptions
DS14 UTIL_3V3 On
DS15 MGTAVCC On
DS16 VCC1V2 On
DS17 MGTAVTT On
DS18 GPIO_LED_7
DS19 VADJ_1V8 On
DS20 12V power available at power input jack J15
DS21 VCCINT On
DS24 VCC1V8 On
DS25 MGTVCCAUX On
DS26 12V On
DS27 SYS_2V5 On
DS28 SYS_1V8 On
DS31 GPIO_LED_7
DS32 GPIO_LED_6
DS33 GPIO_LED_5
DS34 FPGA done
DS36 DDR4 C1 VTT On
DS40 SYS_5V0 On
DS42 SYSCTLR INIT
DS43 SYSCTLR status
DS44 SYSCTLR done
DS45 SYSCTLR error
DS46 SYS_1V0 On
DS47 DDR4 C2 VTT On
DS48 RLD3 C1 VTT On
DS49 UTIL_1V35 On
EPHY J10 RT. GREEN ENET PHY LINK1000
EPHY J10 LFT. GREEN ENET link activity
Table 3-28: VCU118 Board Status and User LEDs (Cont’d)
