Appendix A: FPGA Pinouts
R
RLDRAM II Memory Interface (cont.)
RLD2_D_BY0_B5 F8 RLD2_DM_BY2_3_N T9
RLD2_D_BY0_B6 F9 RLD2_DQ_BY0_B0 G13
RLD2_D_BY0_B7 E8 RLD2_DQ_BY0_B1 F13
RLD2_D_BY0_B8 E9 RLD2_DQ_BY0_B2 N9
RLD2_D_BY1_B0 R11 RLD2_DQ_BY0_B3 N10
RLD2_D_BY1_B1 R7 RLD2_DQ_BY0_B4 E13
RLD2_D_BY1_B2 J6 RLD2_DQ_BY0_B5 E12
RLD2_D_BY1_B3 T6 RLD2_DQ_BY0_B6 L9
RLD2_D_BY1_B4 R6 RLD2_DQ_BY0_B7 M10
RLD2_D_BY1_B5 K6 RLD2_DQ_BY0_B8 E11
RLD2_D_BY1_B6 K7 RLD2_DQ_BY1_B0 J10
RLD2_D_BY1_B7 P6 RLD2_DQ_BY1_B1 B12
RLD2_D_BY1_B8 P7 RLD2_DQ_BY1_B2 A13
RLD2_D_BY2_B0 V9 RLD2_DQ_BY1_B3 H9
RLD2_D_BY2_B1 V10 RLD2_DQ_BY1_B4 H10
RLD2_D_BY2_B2 AK6 RLD2_DQ_BY1_B5 C12
RLD2_D_BY2_B3 AK7 RLD2_DQ_BY1_B6 D12
RLD2_D_BY2_B4 U8 RLD2_DQ_BY1_B7 J11
RLD2_D_BY2_B5 V8 RLD2_DQ_BY1_B8 K11
RLD2_D_BY2_B6 AJ6 RLD2_DQ_BY2_B0 E7
RLD2_D_BY2_B7 AJ7 RLD2_DQ_BY2_B1 E6
RLD2_D_BY2_B8 W9 RLD2_DQ_BY2_B2 G7
RLD2_D_BY3_B0 Y8 RLD2_DQ_BY2_B3 G6
RLD2_D_BY3_B1 AD7 RLD2_DQ_BY2_B4 F6
RLD2_D_BY3_B2 AC7 RLD2_DQ_BY2_B5 F5
RLD2_D_BY3_B3 AB5 RLD2_DQ_BY2_B6 J5
RLD2_D_BY3_B4 AA5 RLD2_DQ_BY2_B7 G5
RLD2_D_BY3_B5 AB7 RLD2_DQ_BY2_B8 H5
RLD2_D_BY3_B6 AB6 RLD2_DQ_BY3_B0 L4
RLD2_D_BY3_B7 AC5 RLD2_DQ_BY3_B1 P5
RLD2_D_BY3_B8 AC4 RLD2_DQ_BY3_B2 N5
RLD2_DM_BY0_1_N G12 RLD2_DQ_BY3_B3 L6
Table A-3: FPGA #3 Pinout (Continued)
Signal Name Pin Signal Name Pin
