Appendix A: FPGA Pinouts
R
DDR400 Component Interface (cont.)
DDR1_DQ_BY0_B4 AM32 DDR1_DQ_BY2_B4 R32
DDR1_DQ_BY0_B5 AM33 DDR1_DQ_BY2_B5 R33
DDR1_DQ_BY0_B6 AL33 DDR1_DQ_BY2_B6 R34
DDR1_DQ_BY0_B7 AL34 DDR1_DQ_BY2_B7 T33
DDR1_DQ_BY1_B0 Y34 DDR1_DQ_BY3_B0 D34
DDR1_DQ_BY1_B1 AA34 DDR1_DQ_BY3_B1 C34
DDR1_DQ_BY1_B2 AA33 DDR1_DQ_BY3_B2 D32
DDR1_DQ_BY1_B3 Y33 DDR1_DQ_BY3_B3 C32
DDR1_DQ_BY1_B4 V34 DDR1_DQ_BY3_B4 C33
DDR1_DQ_BY1_B5 W34 DDR1_DQ_BY3_B5 B33
DDR1_DQ_BY1_B6 V33 DDR1_DQ_BY3_B6 A33
DDR1_DQ_BY1_B7 V32 DDR1_DQ_BY3_B7 B32
DDR1_DQ_BY2_B0 U31 DDR1_DQS_BY0_P AD32
DDR1_DQ_BY2_B1 U32 DDR1_DQS_BY1_P AF33
DDR1_DQ_BY2_B2 T34 DDR1_DQS_BY2_P K33
DDR1_DQ_BY2_B3 U33 DDR1_DQS_BY3_P J32
DDR2 Component Interface
DDR2_A0 K12 DDR2_CAS_N J14
DDR2_A1 K13 DDR2_CK0_N K19
DDR2_A10 G22 DDR2_CK0_P L19
DDR2_A11 J15 DDR2_CK1_N J19
DDR2_A12 K16 DDR2_CK1_P K18
DDR2_A2 H23 DDR2_CKE K17
DDR2_A3 G23 DDR2_CS0_N H20
DDR2_A4 H12 DDR2_CS1_N H19
DDR2_A5 J12 DDR2_LB_BK15 T28
DDR2_A6 K22 DDR2_LB_BK15 T29
DDR2_A7 K23 DDR2_LB_BK19 M28
DDR2_A8 K14 DDR2_LB_BK19 N28
DDR2_A9 L14 DDR2_ODT0 H18
DDR2_BA0 K21 DDR2_ODT1 H17
DDR2_BA1 J22 DDR2_RAS_N H13
Table A-1: FPGA #1 Pinout (Continued)
Signal Name Pin Signal Name Pin
