ZCU102 Evaluation Board User Guide www.xilinx.com 14
UG1182 (v1.2) March 20, 2017
Chapter 2: Board Setup and Configuration
24 SW20 User I/O (CPU_RESET pushbutton switch, active High) E-Switch TL3301EP100QG 53
25
SW8 DIP Switch, 5-pole, GPIO (TI MSP430 System
Controller)
5 pole C&K SDA05H1SBD 38
26
SW3, SW4 Switches (SRST_RESET, POR_B pushbutton switches,
active Low)
E-Switch TL3301EP100QG 12
27
U122, J98 CAN1 (MIO 24-25) (bus transceiver/2x4 male header) TI SN65HVD232,
SULLINS PBC36DAAN
50
28
SW1 Power On/Off Slide Switch (Power On/Off slide
switch)
C&K 1201M2S3AQE2 59
29 J52 Power connector (Power On/Off Slide Switch) MOLEX 39-30-1060 59
30 SW5 Program_B Pushbutton (FPGA program) E-Switch TL3301EP100QG 12
31 J5 FMC HPC0 Connector J5 Samtec ASP_134486_01 26-29
32 J4 FMC HPC1 Connector J4 Samtec ASP_134486_01 30-33
33 J10 Switched output power connector TEC Connectivity 794285-1 59
34 - Power management system (top and bottom) Maxim Regulators 59-86
35 P1 PCI Express Root Port Slot (PCIe 4-lane connector) FCI 10061913-101CLF 43
36 P11 DPAUX (MIO 27-30) (DisplayPort) MOLEX 0472720001 44
37 J84 PMBus connector (Monitoring Voltage and Current) ASSMANN
AWHW16G-0202-T-R
57
38 J92 JTAG connector (TI MSP430 System Controller) TYCO 5103308-2 38
39 J6 ARM JTAG connector (Programmable Logic JTAG
Programming Options)
ASSMANN
AWHW20G-0202-T-R
22
40 U108 HDMI Clock Recovery (HDMI jitter attenuated clock) Silicon Labs SI 5324C-C-GMR 37
41 J3 For more information about PMOD connector
compatible PMOD modules, see [Ref 23]. MPSoC U1
Bank 50 GPIO 2x12 male pin proto header
SULLINS PBC36DAAN
56
42 J70-J72
J79-J80
SMA (MGTH interface SMA connectors) ROSENBERGER
32K10K-400L5
40
43 P6 EMIO ARM Trace Port (ARM Trace receptacle) MICTOR 2-5767004-2 54
44 SW6 Switches (mode 4-pole DIP switch) 4-pole C&K SDA04H1SBD 12
45 (Misc. DSnn) Power and Status LEDs (Misc. LEDs) Miscellaneous LEDs 86
Table 2-1: ZCU102 Board Components (Cont’d)
Callout Ref. Des. Feature/Component Notes
Schematic
0381449
Page Number
To Next Page
