ZCU102 Evaluation Board User Guide www.xilinx.com 94
UG1182 (v1.2) March 20, 2017
Chapter 3: Board Component Descriptions
The ZCU102 board FMC VADJ voltage VADJ_FMC_BUS for the J5 (HPC0) and J4 (HPC1) FMC
connectors is determined by the MAX15301 U63 voltage regulator described in ZCU102
Board Power System, page 110. The valid values of the VADJ_FMC rail are 1.2V, 1.5V, and
1.8V. The HPC0 J5 connections to XCZU9EG U1 are shown in Table 3-44 through Table 3-48.
Table 3-44: J5 HPC0 FMC Section A and B Connections to XCZU9EG U1
J5 Pin Schematic Net Name
I/O
Standard
U1 Pin J5 Pin Schematic Net Name
I/O
Standard
U1 Pin
A2 FMC_HPC0_DP1_M2C_P J4 B1 NC
A3 FMC_HPC0_DP1_M2C_N J3 B4 NC
A6 FMC_HPC0_DP2_M2C_P F2 B5 NC
A7 FMC_HPC0_DP2_M2C_N F1 B8 NC
A10 FMC_HPC0_DP3_M2C_P K2 B9 NC
A11 FMC_HPC0_DP3_M2C_N K1 B12 FMC_HPC0_DP7_M2C_P M2
A14 FMC_HPC0_DP4_M2C_P L4 B13 FMC_HPC0_DP7_M2C_N M1
A15 FMC_HPC0_DP4_M2C_N L3 B16 FMC_HPC0_DP6_M2C_P T2
A18 FMC_HPC0_DP5_M2C_P P2 B17 FMC_HPC0_DP6_M2C_N T1
A19 FMC_HPC0_DP5_M2C_N P1 B20 FMC_HPC0_GBTCLK1_M2C_P
(1)
L8
A22 FMC_HPC0_DP1_C2M_P H6 B21 FMC_HPC0_GBTCLK1_M2C_N
(1)
L7
A23 FMC_HPC0_DP1_C2M_N H5 B24
NC
A26 FMC_HPC0_DP2_C2M_P F6 B25 NC
A27 FMC_HPC0_DP2_C2M_N F5 B28 NC
A30 FMC_HPC0_DP3_C2M_P K6 B29 NC
A31 FMC_HPC0_DP3_C2M_N K5 B32 FMC_HPC0_DP7_C2M_P N4
A34 FMC_HPC0_DP4_C2M_P M6 B33 FMC_HPC0_DP7_C2M_N N3
A35 FMC_HPC0_DP4_C2M_N M5 B36 FMC_HPC0_DP6_C2M_P R4
A38 FMC_HPC0_DP5_C2M_P P6 B37 FMC_HPC0_DP6_C2M_N R3
A39 FMC_HPC0_DP5_C2M_N P5 B40 NC
Notes:
1. Series capacitor coupled to XCZU9EG U1 pin.
