ZCU102 Evaluation Board User Guide www.xilinx.com 99
UG1182 (v1.2) March 20, 2017
Chapter 3: Board Component Descriptions
• 159 ground and 15 power connections
The ZCU102 board FMC VADJ voltage VADJ_FMC_BUS for the J5 (HPC0) and J4 (HPC1) FMC
connectors is determined by the MAX15301 U63 voltage regulator described in ZCU102
Board Power System, page 110. The valid values of the VADJ_FMC rail are 1.2V, 1.5V, and
1.8V. The HPC1 J4 connections to XCZU9EG U1 are shown in Table 3-49 through Table 3-53.
Table 3-49: J4 HPC1 FMC Section A and B Connections to XCZU9EG U1
J5 Pin Schematic Net Name
I/O
Standard
U1 Pin J5 Pin Schematic Net Name
I/O
Standard
U1 Pin
A2 FMC_HPC1_DP1_M2C_P D33 B1 NC
A3 FMC_HPC1_DP1_M2C_N D34 B4 NC
A6 FMC_HPC1_DP2_M2C_P C31 B5 NC
A7 FMC_HPC1_DP2_M2C_N C32 B8 NC
A10 FMC_HPC1_DP3_M2C_P B33 B9 NC
A11 FMC_HPC1_DP3_M2C_N B34 B12 FMC_HPC1_DP7_M2C_P F33
A14 FMC_HPC1_DP4_M2C_P L31 B13 FMC_HPC1_DP7_M2C_N F34
A15 FMC_HPC1_DP4_M2C_N L32 B16 FMC_HPC1_DP6_M2C_P H33
A18 FMC_HPC1_DP5_M2C_P K33 B17 FMC_HPC1_DP6_M2C_N H34
A19 FMC_HPC1_DP5_M2C_N K34 B20 FMC_HPC1_GBTCLK1_M2C_P
(1)
E27
A22 FMC_HPC1_DP1_C2M_P D29 B21 FMC_HPC1_GBTCLK1_M2C_N
(1)
E28
A23 FMC_HPC1_DP1_C2M_N D30 B24 NC
A26 FMC_HPC1_DP2_C2M_P B29 B25 NC
A27 FMC_HPC1_DP2_C2M_N B30 B28 NC
A30 FMC_HPC1_DP3_C2M_P A31 B29 NC
A31 FMC_HPC1_DP3_C2M_N A32 B32 FMC_HPC1_DP7_C2M_P G31
A34 FMC_HPC1_DP4_C2M_P K29 B33 FMC_HPC1_DP7_C2M_N G32
A35 FMC_HPC1_DP4_C2M_N K30 B36 FMC_HPC1_DP6_C2M_P H29
A38 FMC_HPC1_DP5_C2M_P J31 B37 FMC_HPC1_DP6_C2M_N H30
A39 FMC_HPC1_DP5_C2M_N J32 B40 NC
Notes:
1. Series capacitor coupled to XCZU9EG U1 pin.
