80
series motor dimension
Unit:
mm
Motor model
Body length
Inertia level
Normal
W
ith brake
MS5S-80ST
-
CS02430□□
-20P7-SO1
107±
1
144±
1
Small inertia
MS5S-80ST-
CS03230□□
-21P0-SO1
128±
1
165±
1
MS5H-80ST
-
CS02430□□
-20P7-SO1
1
19
±
1
156±
1
Lar
g
e inertia
MS5H-80ST-
CS03230□□
-21P0-SO1
140±
1
177±
1
23
25
