Xinje DS5B Series User Manual

zero calibration
over limit
operation error
value when calibrating
3
E-093
Analog Vref
zero calibration
over limit
Analog zero calibration
operation error
Please not add analog
value when calibrating
10
0
E-100
Position offset
too large
The difference between
setting position and
actual position is over
the limit
1. check whether the
motor stall, decrease the
position setting speed
2. increase the offset pulse
limit P0-23
11
0
E-110
Motor UVW
short circuit
1.external short circuit
when self-checking
2. load blocked
1. check motor UVW
wiring
2. change drive
3. change motor
4. suggest to run without
load, to troubleshoot load
problem
12
0
E-120
Current sensor
error
Current sensor damaged
or external interference
too large
Check the ground wiring
or contact us
1
E-121
U phase current
sampling zero
calibration
value error
Current sensor damaged
or external interference
too large
Check the ground wiring
or contact us
2
E-122
V phase current
sampling zero
calibration
value error
Current sensor damaged
or external interference
too large
Check the ground wiring
or contact us

Xinje DS5B Series Specifications

General

Brand	Xinje
Model	DS5B Series
Category	Servo Drives
Language	English
